Dimensions

Article Diameter (in mm) 1168

Article Height (in mm) 295

Canopy Height (in mm) 50

Canopy Diameter (in mm) 170

Net Weight 6.1 Kilogram

Gross Weight 7 Kilogram

Single-Box Height (in mm) 252

Single-Box Length (in mm) 596

Single-Box Depth (in mm) 428

Fan

Motor Type DC

Motor dimension in MM (Ø x H) 155x12

Motor Wattage 22

Adjustable Canopy 13°

Blade pitch in degree 16°

Blade Quantity 3 Mains

Voltage 220-240V, 50Hz

Performance

Wattage by air movement (1) 2

RPM (1) 62

Air Movement m3/Hr (1) 3230

Wattage by air movement (2) 3

RPM (2) 89

Air Movement m3/Hr (2) 5780

Wattage by air movement (3) 4

RPM (3) 110

Air Movement m3/Hr (3) 7390

Wattage by air movement (4) 7

RPM (4) 140

Air Movement m3/Hr (4) 9530

Wattage by air movement (5) 10

RPM (5) 167

Air Movement m3/Hr (5) 11420

Wattage by air movement (6) 20

RPM (6) 200

Air Movement m3/Hr (6) 14620
