Dimensions
Article Diameter (in mm) 1320
Article Height (in mm) 338
Canopy Height (in mm) 66
Canopy Diameter (in mm) 152
Net Weight (in kg) 5.6 Kilogram
Gross Weight 6.8 Kilogram
Single-Box Height (in mm) 250
Single-Box Length (in mm) 700
Single-Box Depth (in mm) 325

Fan
Motor Type DC
Motor dimension in MM (Ø x H) 132,5 x 10
Motor Wattage 70
Adjustable Canopy 13°
Blade pitch in degree Variable
Blade Quantity 3
Protection Degree IP20
Mains Voltage 220-240V, 50Hz

Function
timer
CCT
reversible
6 speeds

Material & Colour
Blade Material ABS
Canopy Material ABS
Enclosure Material ABS
Glass/Shade Material acrylic
Glass/Shade Colour milky

Performance
Wattage by air movement (1) 3.3
RPM (1) 70
Air Movement m3/Hr (1) 2894
Wattage by air movement (2) 5.5
RPM (2) 105
Air Movement m3/Hr (2) 4860
Wattage by air movement (3) 10
RPM (3) 140
Air Movement m3/Hr (3) 6690
Wattage by air movement (4) 15.5
RPM (4) 170
Air Movement m3/Hr (4) 8740
Wattage by air movement (5) 27
RPM (5) 200
Air Movement m3/Hr (5) 10100
Wattage by air movement (6) 40
RPM (6) 230
Air Movement m3/Hr (6) 12640

Illuminant
Illuminant Type (1) LED
max. Wattage (1) 20W
Light colour Complete TUNEABLE WHITE
